CCNP Routing and Switching Portable Command Guide
- By Scott D. Empson, Patrick Gargano, Hans Roth
- Published Dec 22, 2014 by Cisco Press. Part of the Portable Command Guide series.
Book
- Sorry, this book is no longer in print.
eBook
- Your Price: $30.39
- List Price: $37.99
- Includes EPUB and PDF
- About eBook Formats
This eBook includes the following formats, accessible from your Account page after purchase:
EPUB
The open industry format known for its reflowable content and usability on supported mobile devices.
PDF
The popular standard, used most often with the free Acrobat® Reader® software.
This eBook requires no passwords or activation to read. We customize your eBook by discreetly watermarking it with your name, making it uniquely yours.
About
Features
- Maps to the latest version of the CCNP Routing and Switching Exam - great for review before exams without needing a computer connected to a Cisco device
- All commands in a small, compact resource — makes it easy to carry as a reference in the workplace
- Examples of how to use commands are given at the same time as the command is presented
Description
- Copyright 2015
- Dimensions: 6" x 9"
- Pages: 416
- Edition: 1st
- Book
- ISBN-10: 1-58714-434-4
- ISBN-13: 978-1-58714-434-9
CCNP Routing and Switching Portable Command Guide
All ROUTE (300-101) and SWITCH (300-115) Commands in One Compact, Portable Resource
Preparing for the CCNP® ROUTE or CCNP SWITCH exam? Working as a network professional? Here are all the CCNP-level commands you’ll need, in one handy resource. The CCNP Routing and Switching Portable Command Guide is filled with valuable, easy-to-access information, and it’s portable enough to use whether you’re in the server room or the equipment closet.
This guide helps you memorize commands and concepts as you prepare to pass the CCNP ROUTE (300-101) or CCNP SWITCH (300-115) exams. It summarizes all CCNP certification-level Cisco IOS® Software commands, keywords, command arguments, and associated prompts, offering tips and examples for applying them in real-world environments. Throughout, configuration examples deepen your understanding of how these commands are used in actual network designs.
Whenever you’re researching routing or switching solutions, you won’t find a quicker, more useful offline resource.
--Logical “how-to” topic groupings inside the front and back covers provide one-stop research
--Compact size makes it easy to carry with you, wherever you go
--Helps you review important commands before taking the CCNP ROUTE or CCNP SWITCH certification exam
--“Create Your Own Journal” appendix with blank, lined pages enables you to personalize the book for your own needs
--“What Do You Want to Do?” chart inside front and back covers helps you to quickly reference specific tasks
Sample Content
Online Sample Chapter
CCNP Routing and Switching Portable Command Guide: Configuration of Redistribution
Sample Pages
Download the sample pages (includes Chapter 4 and Index)
Table of Contents
